Where to Put Knobs and Pulls on Kitchen Cabinets

Getting cabinet hardware placement right is one of the smallest decisions in a kitchen remodel and one of the most visible, so this guide walks you through exactly where to put knobs, pulls, and edge pulls on every cabinet type in your kitchen. The placement rules below apply to framed and frameless boxes alike, from Fabuwood cabinets to Jarlin and every line we carry, and they work with every style in our knobs and pulls collection.

Knobs on Doors, Pulls on Drawers: The Classic Rule

The most widely used convention in kitchen design is simple: knobs go on cabinet doors, and pulls go on drawers. Knobs are compact and work well on doors because you are swinging the door open with one hand and do not need much grip length. Pulls are longer and give your fingers a firmer grip on a drawer, which you slide straight out against resistance from whatever is loaded inside.

That said, the rule is not absolute. Many homeowners use pulls on both doors and drawers for a more streamlined look, particularly with shaker cabinet doors where the clean rail lines complement a bar pull nicely. Using the same hardware style throughout creates a cohesive feel, and mixing knobs on doors with pulls on drawers adds a traditional, layered character. Either approach works as long as placement is consistent across the kitchen.

Pick one finish and carry it through the whole kitchen: matte black, brushed nickel, chrome, gold and brass, or oil-rubbed bronze. Then match the shape to the door, with modern bar pulls on slab and frameless doors, transitional hardware on shaker doors, and traditional knobs on raised panel doors.

Door Hardware Placement: The 2-to-3 Inch Rule

For framed cabinet doors, the standard placement puts hardware on the stile (the vertical frame member) opposite the hinge, positioned 2 to 3 inches from the nearest corner of the door. The exact distance depends on the size of the door and the scale of the hardware, but staying in that range keeps everything looking intentional rather than accidental.

The vertical position changes depending on whether the door is on a base cabinet or a wall cabinet:

• Base cabinet doors: Place the knob or pull near the top of the door, on the stile opposite the hinge. This mimics a natural lifting motion when you reach down to open a lower cabinet.
• Wall cabinet doors: Place the knob or pull near the bottom of the door, on the stile opposite the hinge. Reaching up to open a wall cabinet feels natural when the hardware is at the lower corner.

On inset doors and full-overlay frameless doors (such as those on frameless cabinet boxes), the same corner-placement logic applies, but you are measuring from the edge of the door panel itself rather than from a face-frame stile.

Drawer Pull Placement: Centered Every Time

Drawer pulls are almost always centered horizontally on the drawer front. For the vertical position, center the pull on the height of the drawer front as well. On a standard 6-inch-tall drawer front, that puts the pull at 3 inches from the top and bottom edges.

Wide drawers (typically 24 inches or wider) often look and function better with two pulls rather than one. Space them evenly, positioning each pull roughly one-quarter of the drawer width in from each side. Two pulls also make it easier to open wide drawers with both hands, which matters on heavy pots-and-pans drawers. For a standard 30-inch-wide drawer, that means one pull about 7 to 8 inches in from each side.

Pantry Doors and Tall Cabinet Doors

Pantry cabinets and tall oven-tower doors present a placement challenge because the door is much taller than a standard base or wall cabinet door. Two approaches work well:

• Single pull at comfortable reach height: Position one pull at roughly 36 to 42 inches from the floor, centered on the stile opposite the hinge. This puts the hardware at a natural hand height for most adults without stretching or crouching.
• Two pulls for double pantry doors: On a two-door pantry, place one pull near the top of each door and one near the bottom, or place a single pull at comfortable height on each door. The symmetry reads well and the hardware stays functional.

On tall doors, a long pull (10 inches and up) is easier to grab than a knob and keeps the hardware in scale with the door.

If your pantry has a two-panel door (one taller panel above and one shorter panel below), you can treat each panel independently using the base-cabinet and wall-cabinet rules: hardware near the top of the lower panel and near the bottom of the upper panel, both on the stile opposite the hinge.

Edge Pulls on Slab Doors

Flat-front slab cabinet doors have no frame rail or stile detail to anchor traditional hardware. Edge pulls (sometimes called finger pulls or J-pulls) mount to the edge of the door itself and are nearly invisible from the front, which suits the clean, minimalist look that slab doors are chosen for.

For edge pulls on slab doors:

• Mount the pull on the edge of the door opposite the hinge, positioned at the vertical center of the door for most base and wall cabinets.
• On tall or pantry slab doors, center the pull at comfortable hand height (roughly 36 to 42 inches from the floor).
• On slab drawer fronts, edge pulls are centered horizontally along the top edge of the drawer front.

You can also use a recessed or surface-mounted bar pull on slab doors if you prefer hardware that reads from the front. In that case, follow the same 2-to-3-inch-from-the-corner placement used on framed doors, centering the pull along the edge side of the door panel.

Hardware Placement by Cabinet Type: Quick Reference

Using a Drilling Template

A hardware drilling template is the single most useful tool for this job. Templates hold the drill bit at the correct distance from the corner of the door or the center of the drawer front, so every hole lands in exactly the right spot without re-measuring each cabinet.

Most templates are adjustable and work for knobs (single hole) and pulls (two holes at a fixed center-to-center distance such as 3 inches or 96 mm). Before you drill, confirm the center-to-center measurement on your pulls, check it against your template, and drill one test hole on a scrap piece of wood. Every pull we sell lists its center-to-center size, and you can shop by size: 3-inch, 3-3/4-inch (96 mm), 5-inch (128 mm), 6-1/4-inch (160 mm), 7-1/2-inch (192 mm) and 10-inch pulls. Doors on a kitchen like a Fabuwood kitchen or a Jarlin kitchen arrive with a factory finish, so there is no correcting a hole drilled in the wrong place without a backplate cover. Take the time to measure twice and drill once.

If you are still in the planning stage and have not chosen your cabinet door style yet, it helps to see the door in person first. You can order door samples to check the finish and profile before committing. And if you want a complete layout with hardware, countertops, and cabinet placement visualized together, our free 3D kitchen design service shows you the whole picture before you order a single cabinet.
