The Jarlin Cabinetry Product Catalog 2026 is the manufacturer's spec book: every door style, construction detail and cabinet code in the line, with sizes, weights and a door-by-door availability chart. You can download the 2026 PDF below. This guide walks through what is on each page, how to read the codes, and how to turn the book into an accurate order for your kitchen or bath.
Download the Jarlin Cabinetry Spec Book (PDF)
The complete 2026 book from Jarlin: 80 pages, PDF, 10.6 MB. It is Jarlin's own 2026 product catalog.
Download the PDF Shop Jarlin CabinetryWhat Is in the Jarlin Cabinetry Spec Book
The 2026 Jarlin catalog runs 80 pages. The page numbers below are the ones printed at the bottom of each page, which is how the table of contents counts them. Your PDF viewer counts the cover as page 1, so its number runs one ahead.
| Section | Pages | What you will find there |
|---|---|---|
| Cabinet Door Styles | 3-10 | All 16 doors with finish and construction |
| Superior Cabinet Construction | 11 | Labeled cutaway of a wall and base cabinet |
| Wood Species and Characteristics | 12 | Natural grain and color variation |
| Fine Furniture Finish | 13 | The 13 step finishing process |
| NKBA Kitchen Guidelines | 14-15 | Planning clearances and work areas |
| Cabinet Dimensions | 16-17 | Standard heights, rails, toe kick, overlay |
| Installation Guidelines | 18-20 | 84, 90 and 96 inch layouts |
| Kitchen Gallery | 21-38 | Kitchen photos by door style |
| How To Use the Catalog | 39 | How to read a cabinet code |
| Base Cabinets | 40-46 | Base, drawer, sink and corner bases |
| Wall Cabinets | 47-50 | Wall, corner wall and bridge cabinets |
| Pantry | 51 | Single and double door tall pantries |
| Vanities | 52-54 | Vanity sink bases and drawer bases |
| Specialty, Moldings and Accessories | 55-69 | Moldings, fillers, panels, inserts |
| Glass Door and Deco Door | 70-73 | Glass doors, dummy doors, sample door |
| Cleaning and Care | 74 | Care and touch-up |
| Policies and General Information | 75-77 | Receiving, returns, damaged parts |
| Warranty Information | 78 | Three year limited warranty |
Each specification table lists the SKU, the weight in pounds, the size as width x height x depth, and a dot under every door style that offers that code.
Door Styles and Finishes Covered
Pages 3-10 show 16 door styles, each with its wall door and base door side by side. Every style comes in one finish, so the door name and the color go together. The two-letter code is the column heading you will look for in the spec tables.
| Door style (code) | Finish | Door |
|---|---|---|
| Charlton (CT) | Coffee | Raised panel, solid wood |
| Newport (NT) | Cinnamon | Raised panel, solid wood |
| Perla (PE) | Cream White | Raised panel, birch frame, MDF center |
| Avalon (AL) | Off White | Raised panel, birch frame, MDF center |
| Ebony Shaker (ES) | Espresso | Reversed raised panel, solid wood |
| Smoky Gray (SM) | Stained Gray | Reversed raised panel, solid wood |
| Dove White Shaker (DS) | Dove White | Reversed raised panel, birch frame, MDF center |
| Soda (SO) | White | Reversed raised panel, birch frame, MDF center |
| Sterling (SG) | Gray | Reversed raised panel, birch frame, MDF center |
| Aria Blue (AB) | Blue | Reversed raised panel, birch frame, MDF center |
| Toffee Shaker (TS) | Toffee Stain | Birch frame, veneered MDF reversed raised panel |
| Weston Shaker (WS) | Bright White | HDF center panel |
| Cream White Shaker (CS) | Cream White | HDF center panel |
| Sage Green Shaker (GS) | Sage Green | HDF center panel |
| Sandy Mirage Shaker (SS) | Cashmere | HDF center panel |
| Unfinished Birch Shaker (US) | Unfinished Birch | Birch frame, veneered HDF reversed raised panel |
The four raised panel doors (Charlton, Newport, Perla, Avalon) give the traditional look. The reversed raised panel doors read as a shaker profile, and the HDF group (Weston, Cream White, Sage Green, Sandy Mirage) is a flat panel shaker. Unfinished Birch Shaker ships ready for your own finish, and the book notes that unfinished BP3696 skin panels are required on its exposed sides.
Printed color can only approximate the real finish, and the back cover says so. The catalog lists a SAMPLE DOOR (12 x 15 x 3/4) in all 16 styles on page 73.
Construction and Specifications
Page 11 labels the construction features on a cutaway wall and base cabinet:
- Box: 1/2 inch thick cabinet grade plywood, with metal bracket reinforcements in base cabinets.
- Face frame: 3/4 x 1 1/2 inch hardwood with double doweled joints.
- Doors and drawers: full overlay, 3/4 inch thick panels, with door bumpers.
- Hinges: 6 way adjustable European style, fully concealed, soft closing.
- Drawer box: dovetail, 5/8 inch thick solid wood sides without finger joints.
- Glides: full extension, soft closing, under-mount and concealed.
- Shelves: adjustable 3/4 inch shelves on metal shelf rests, and an 18 inch deep base shelf.
- Interior: natural birch finish interior.
The finish page (13) lays out 13 steps, including hand applied stain or paint, a color inspection station, an oven cured sealer coat, a catalyzed clear top coat and a final inspection. Glazed product gets the glaze hand applied after seal sanding.
Standard sizes are on pages 16-17. Base cabinets are 34 1/2 inches high and 24 inches deep, with an inset toe kick 4 1/2 inches high and 3 inches deep. Wall cabinets come in 12, 15, 18, 24, 30, 36 and 42 inch heights, and tall cabinets in 84, 90 and 96. One note is worth reading twice: include at least a 1 inch filler between the hinged side of a full overlay door and any deeper cabinet, wall, appliance or countertop next to it.
The warranty on page 78 is a three year limited warranty for the original purchaser, and the drawer box, drawer glides and hinges are covered for as long as the original purchaser owns the home. It applies to residential use in the United States and is non-transferable. For a broader look at the line, see Is Jarlin a good cabinet brand?
How to Read the Cabinet Codes
Page 39 explains the system. Letters name the cabinet type and numbers give the size in inches, width first. Base cabinets list width only, because every base is 34 1/2 inches high and 24 inches deep, so B24 is a 24 inch base. A drawer base adds the drawer count: DB24-3 has three drawers.
Wall cabinets list width, then height. W2430 is 24 wide and 30 high. The standard 12 inch depth is left out, so a third number only appears when the depth changes: W361224 is 36 wide, 12 high and 24 deep. Tall cabinets work the same way against a standard 24 inch depth, so WP2490 is 24 wide and 90 high, and WP249018 is the same pantry at 18 inches deep.
Vanity sink bases (FA) and drawer bases (SVA) are 34 1/2 inches high and 21 inches deep. DL and DR versions mirror the door and drawer layout, so check the drawing beside each code.
| Code | What it is | Page |
|---|---|---|
| B30 | Base, 1 drawer, 2 doors, 30 x 34 1/2 x 24 | 40 |
| DB18-3 | Drawer base, 18 inches wide, 3 drawers | 42 |
| SB36 | Sink base, 36 wide, 2 dummy drawer faces, 2 doors | 43 |
| SB36-S | Farm sink base; opening can be cut to fit 33 or 36 | 43 |
| BBC42 | Base blind corner, 42 inches, 18 inch door and drawer | 44 |
| BLS36N | Lazy susan base, folding doors, no tray, 1 shelf | 44 |
| BSR09 | Base spice pull out, 9 inches wide | 45 |
| W3030 | Wall, 30 wide, 30 high, 12 deep, 2 doors | 47 |
| WDC2436 | Wall diagonal corner, 24 x 36 x 12 | 48 |
| W361224 | Wall bridge (stacker), 36 wide, 12 high, 24 deep | 50 |
| WP2490 | Double door tall pantry, 24 wide, 90 high | 51 |
| OC31.590 | Oven pantry, 31 1/2 x 90 x 24, 3 drawers, 2 doors | 52 |
| SVA18D | Vanity drawer base, 18 x 34 1/2 x 21, 3 drawers | 54 |
Check the dots before you finalize a code, because not every size is made in every door. The full door bases (B15FD through B36FD) show only Dove White and Toffee Shaker, and the 42 inch vanities (FA4221DL, FA4221DR) show only Dove White and Sterling.
Modifications and Accessories
The Jarlin catalog has no modifications section. It covers finishing work through its specialty and accessory pages (55-69) and glass and decorative doors (70-73).
Moldings
Crown is matched to the door family. Raised panel doors use ACM8 (2 1/2 x 96) and CCM8 classic crown (3 1/4 x 96), and the shaker doors use CM8-C shaker cove crown and CM8-S shaker angled crown. Light rail is TLR8-1 for the raised panel group and TLR8-2 for the shakers. All 16 styles offer BM8 base board molding, TK8 toe kick (4 1/2 x 1/4 x 96), QRM8 quarter round, SM8 scribe and OCM8 outside corner molding.
Fillers, panels and extras
- Fillers: wall fillers WF330 through WF696, and base fillers BF3 and BF6.
- Panels: BP3696 and BP4896 skin panels (1/4 inch, two sides finished) and FP2496, FP3696 and FP4896 (3/4 inch, two sides and four edges finished).
- Appliance panels: RRP96 refrigerator panel and DWP dishwasher panel, each with a 3 inch return.
- Storage: WBS18-2 and WBS15-1 waste basket pull outs (35 quart cans), ROT roll out drawers with dovetail joints, POK pot and pan kits for B24 to B36, and the BLSTRAY lazy susan tray.
- Decorative: turn posts, corbels, onlays and valances (V30SH through V72SH).
Glass doors
Glass doors use textured glass and a WM code that matches the cabinet, so a W1212 takes a WM1212. Mullion glass doors are made for Charlton, Perla, Newport and Avalon, and open frame glass doors for the shaker styles. A 30 inch wide cabinet uses two WM15 doors.
How to Use the Spec Book When You Order
- Measure first. Our guide on how to measure a kitchen for cabinets walks through it. The layouts on page 18 help you choose wall and tall heights.
- Build the list by code. Pick your door, then work wall by wall through the base, wall and tall tables, checking the dot under your door code on every line.
- Add the finishing pieces. Fillers, the 1 inch overlay filler, end panels, toe kick and crown. Our checklist on fillers, panels and toe kicks covers what people most often leave off.
- Confirm the color. Order door samples and look at them in your own light.
- Decide assembled or RTA. The policies pages cover both. Our comparison of Jarlin assembled vs RTA explains the difference.
Send us your measurements or code list for a free 3D kitchen design and an itemized quote. We can price any code in this book, including items not listed on our site, if you send us the code. Prices for listed items are live on our Jarlin cabinets page.
At delivery, the receiving steps on page 75 are worth following: count the pieces against the delivery receipt, then photograph and note any damage on the receipt before you sign. Shoppers who want the widest finish selection and Designer options should also look at Fabuwood, our premium line.
