Fabuwood Value Premium Spec Book 2026: PDF Guide

The Fabuwood Value Premium Spec Book is Fabuwood's 78-page specifications guide for the Value Premium line, listing every cabinet code, accessory, molding, panel and modification it builds, plus the construction specs behind them. You can download the 2026 PDF below. This guide walks through what is on each page, how the Hallmark Frost door is built and how to read codes like B30, W3036 and TP182490.

What Is in the Fabuwood Value Premium Spec Book

The 2026 edition is titled the Value Premium Specifications Guide and is marked valid through September 2026. The front section uses Roman numeral page numbers, and the cabinet catalog starts on page 11. Page numbers below are the ones printed on each page.

Fabuwood notes that items can change without notice. If a code in the PDF above looks different from our site, send it to us and we will check it.

Door Styles and Finishes Covered

This is the simplest Fabuwood book to choose from. Value Premium is built in one door style, Hallmark, in one finish, Frost paint. Every cabinet, filler, molding and panel code in the book is made in that combination.

The modified overlay on the wall cabinets is there for a reason: the book says the overlay on top of all wall cabinets is set up to accept crown molding, so crown can be mounted on the face frame. Base cabinets get a full overlay door.

The paint (by the pint or quart), the paint spray can and the touch-up kit on page 53 are all listed in Frost. Page VIII lists three Hallmark Frost door samples: SDHF (small door sample), SDHF-2 (door sample with drawer front) and SDHF-3 (medium door sample with drawer front).

If you want more door styles and finishes than Hallmark Frost, the rest of the Fabuwood range, including the Allure and Designer options, is on our Fabuwood cabinets page.

Construction and Specifications

Pages IV and V spell out how every Value Premium cabinet is built. These are the numbers the book gives:

• Doors and drawer fronts: full HDF construction for doors, drawer fronts, rails and center panels, which Fabuwood says reduces the possibility of shrinkage. Stiles and rails are 3/4" thick and 2-1/4" wide with mortise and tenon joints.
• Hinges: Compact Blumotion soft-close hinges (Blum model 39C355B.20), concealed and six-way adjustable, opening to 110 degrees.
• Drawers: 5/8" solid wood dovetail drawer box with a 3/8" plywood bottom, on Tandem plus Blumotion full-extension concealed runners (Blum model 563H).
• Box: 1/2" veneered plywood sides and back with natural finished interiors, grooved into the face frame. Backs are stapled and screwed. Tops and bottoms are 3/4" veneered plywood grooved into the sides and back.
• Face frame: 3/4" x 1-1/2" solid wood stiles and rails joined with glue and dowels. The bottoms of base and wall cabinets sit flush with the top inside edge of the face frame.
• Shelves: 15mm (5/8") select veneered plywood adjustable shelves with matching wood edge banding, on plastic self-locking shelf clips. The base cabinet shelf is 11-7/8" deep.
• Toe kick: a 3/4" x 4-1/2" unfinished plywood toe kick is attached to each assembled cabinet. The matching 1/4" toe kick cover (TK8, 8 foot lengths) is ordered separately.
• Panel beams: 2-1/2" x 1/2" plywood beams dovetailed in at the top of each base cabinet for strength and for mounting the countertop.
• Finished ends: when you order, you pick the exposed side (right, left or both). A 1/4" MDF panel is applied to that side for a near-flush finished end.

On warranty, page VI states that Value Premium cabinets purchased on or after October 1, 2024 carry Fabuwood's Limited Lifetime Warranty for the first residential purchaser, covering defects in material and workmanship for as long as that owner owns the home. Cabinets bought before that date fall under the Limited 5-Year Warranty. The warranty page also lists exclusions, including Blum hinges and other third-party accessories.

How to Read the Cabinet Codes

Value Premium codes follow a simple pattern: a letter prefix for the cabinet type, then the width in inches, then the height (and sometimes depth). W3036 is a wall cabinet 30" wide and 36" high. B30 is a base 30" wide. Tall pantry codes add depth before height, so TP182490 reads as 18" wide, 24" deep, 90" high.

The standard sizes by category, from the drawings in the book:

• Wall cabinets: 12" deep, in heights of 12, 15, 18, 30, 36 and 42 inches. A 24" deep series (W2424 to W362424) covers 15, 18 and 24 inch heights.
• Base cabinets: 34-1/2" high and 24" deep, from B09 to B42.
• Tall pantries and oven cabinets: 24" deep, in 84, 90 and 96 inch heights. Pantries have five shelves at 84" and six at 90" and 96", all 18" deep.
• Vanities: 34-1/2" high and 21" deep.

A few suffixes are worth knowing. On oven cabinets, S is single (three drawers), C is combo (two drawers) and D is double (one drawer). On vanity combos, DR and DL set which side the drawers go on, and the book notes the cabinet cannot be reversed after it is assembled. For a wider look at standard sizes across brands, see our kitchen cabinet sizes guide.

Vanity tops use VT plus width and color, from VT24 to VT60 (single or double sink), in Cloud, Moonstone, Desert Silver or Miami Vena. Each is 22" deep with a 4" backsplash and an integrated sink.

Modifications and Accessories

The modification section (pages 57 to 69) is where Value Premium gets flexible. The most useful ones:

• Depth reductions: CUT-BASE and CUT-DBASE (12" minimum), CUT-WALL (4" minimum), CUT-SBASE and CUT-TALL (no minimum).
• CUT-BASE HEIGHT: removes the top drawer to make a 28-1/2" base for a range top.
• CUT-DOOR: cuts out the center panel for a glass insert, glass not included. MATCH-INTERIOR is added separately.
• CUT-TK and RECESS-TK: reduce the toe kick height or recess it on the left, right or back.
• PEN-CABINET: creates a peninsula cabinet from two cabinets.
• Depth increases: INCREASE-BASE, INCREASE-WALL and INCREASE-TALL.
• Pipe chases: CHASE-BASE, CHASE-DBASE, CHASE-WALL, CHASE-TALL and CHASE-CORNER, each requiring a drawing.
• FULL-DOORS: a full-height door on single door bases. The book notes cabinets 24" wide and up need custom doors through Fabuwood's custom quotes.
• Custom sizes: CUSTOM DOOR, CUSTOM DRAWER FRONT and CUSTOM DECO PANEL in 1/16" increments, with extended lead times.

Glazing is listed as an upgrade (GLAZE) on page 70. Loose finished end skins (SK BASE, SK TALL, SK W30, SK W36, SK W42, SK MC) and edge banding by the linear foot are on page 71.

For trim, the book covers wall fillers (WF330 to WF642), tall fillers (TF396, TF696), base fillers (BF3, BF6) and overlay fillers (OLF codes). Moldings come in 8 foot lengths: CM-1 small crown, outside and inside corner pieces (OCM8, ICM8), light rail (LRM), scribe (SM8), quarter round (QRM), base and batten moldings (BBM, BM3/4) and the TK8 toe kick. Panels include dishwasher end panels (DWR1-1/2, DWR3, DWR6), refrigerator end panels (REP1-1/2, REP3, REP2496), wainscot panels (WP-BASE, WP-W30 to WP-T96), deco doors (DD B09FD to DD B21FD) and plywood sheets.

Storage accessories include Blum trash pull-outs (TC15 BLUM to TC21 BLUM), roll outs (ROD-B15 to ROD-B36), spice and utensil pull-outs, lazy susans, appliance garages and a charging drawer (CHD-B18 BLUM).

How to Use the Spec Book When You Order

This is the order we recommend:

• Measure the room. Record wall lengths, ceiling height, windows, doors and appliance locations. Our guide to measuring a kitchen for cabinets shows each step.
• Build your list by code. Pick each cabinet from the pages above and write the exact code, such as B30, DB18 or W3036. Use the height alignment guide on pages 72 to 75 to match your wall and tall cabinets to your overall height.
• Add fillers, panels and toe kick. Blind corners need a filler on the adjacent side, and exposed ends need to be specified. Our guide to fillers, panels and toe kicks covers what most orders need.
• Confirm the color. Order door samples to see Hallmark Frost in your own light before you commit.
• Send us the list. We will turn it into a free 3D design and an itemized quote.

You can shop the line on our Fabuwood Value Premium cabinets page, where prices are live. The spec book is not a price list, and not every code in it appears on our site. Send us any code from the book, including modifications and accessories, and we will price it for you. Our Fabuwood cabinets price list shows how the lines compare.
