CNC Cabinetry Spec Book 2026: PDF and Buyer's Guide

The CNC Cabinetry spec book is the manufacturer's full product catalog for its Bedford, Luxor, Concord and Classic collections, and you can download the 2026 PDF below. It lists every door style and finish, the box construction for each collection, and every cabinet code with its sizes. This guide shows where to find each section and how to read the codes so you can build an accurate order.

What Is in the CNC Cabinetry Spec Book

The 2026 book runs 308 pages. It opens with what changed this year, then general information, then a full section for each collection with the door specs, every cabinet, and the fillers, moldings and modifications that go with it. The page numbers below are the ones printed on each page; your PDF viewer's counter runs one number higher.

If you only need one collection, jump straight to it. Each collection section follows the same order, so once you learn one, the others read the same way.

Door Styles and Finishes Covered

CNC groups its doors into four cabinet collections. Bedford doors are standard overlay with a 1 inch reveal. Luxor is semi-full overlay with a 1/2 inch reveal (Glencove is full overlay), Concord is full overlay with a 1/4 inch reveal, and Classic is frameless with a 1/8 inch reveal. Vanguard vanities sit at the back of the book in VG10 White.

The Plus Program is CNC's expanded color list for Concord and Classic: ten paints (101 Sleek White, 102 Linen, 103 Sahara, 104 Mountain Stream, 105 Adirondack Blue, 106 Sage, 107 Evergreen, 108 Rumors, 109 Cracked Pepper, 110 Jet Black) and three stains (200 Ale, 201 Bourbon, 202 Wheat). The book notes the paints are not offered on the Park Ave, Milano or Broadway doors, and the stains are listed for Newport, Sydney, Versailles and Woodbourne. Every Plus order needs its finished sides called out.

Construction and Specifications

Construction changes more between CNC collections than the door does, so read the door specs page for the collection you are pricing. All four use a 4 1/2 inch toe kick and 3/4 inch plywood shelves.

Bedford (pages 36-38)

All plywood with a 3/4 inch thick, 1 1/2 inch wide kiln-dried hardwood face frame and 1/2 inch plywood backs and ends. Drawer boxes are 1/2 inch plywood on epoxy coated side mount glides, and Dover includes soft-close hinges. There is no five-piece drawer front upgrade and no finished interior option.

Luxor (pages 66-68)

A 3/4 inch thick, 1 1/2 inch wide kiln-dried solid hardwood frame over 1/2 inch plywood backs and ends, dado jointed. Drawers have 5/8 inch solid wood dovetail sides and a 3/8 inch bottom on soft-close undermount glides (3/4 extension on Luxor, full extension on Glencove). Hinges are concealed and soft-close, with three hinges on 36 and 42 inch wall cabinets.

Concord (page 122)

The 3/4 inch hardwood face frame joins 1/2 inch plywood sides with a dado interlocking system, and the full 1/2 inch plywood back has 3 inch hanging rails. Drawers are 3/4 inch solid wood dovetail on stainless steel full extension undermount soft-close glides, and hinges are six-way adjustable soft-close clip-on. Plus Program orders upgrade hinges and glides to BLUM.

Classic (pages 202-207)

Frameless, in a White box or a Maple box. Sides are 3/4 inch plywood assembled with glue, screws and wood dowels, over a 3/4 inch full back. The White box uses a double wall white metal drawer with a 1/2 inch plywood bottom, and the Maple box uses 3/4 inch solid wood dovetail drawers, both on full extension soft-close glides. Classic ships assembled only.

Warranty (pages 304-305)

Luxor, Concord and Classic carry a Limited Lifetime Warranty and Bedford a Limited Five-Year Warranty, both covering defects in material and workmanship for the original residential purchaser. Replacement covers parts, not labor.

How to Read the Cabinet Codes

CNC codes put the cabinet type first, then the width, then any height or depth, then suffixes. The Cabinet Code Key on page 16 uses three examples: B24 is a 24 inch wide base, 2430X24 is a wall cabinet 24 wide by 30 high by 24 deep, and V48DD is a 48 inch vanity with double drawers.

Standard wall cabinets are 12, 15, 18, 24, 30, 36 or 42 inches high and 12 or 24 inches deep. Wall codes without a prefix are just width then height, so 3036 is 30 wide by 36 high. Base cabinets are 34 1/2 inches high and 24 inches deep. Tall cabinets are 84, 90 or 96 inches high and 21 or 24 inches deep. Vanities are 21 inches deep and 34 1/2 inches high in Dover, Luxor, Concord and Classic.

The suffixes to know: FH (full height door), POS (pull out shelf), POD (pull out drawer), L/R (door hinged left or right), FL/FR (finished left or right side), F2 (finished two sides), 5P (five-piece drawer front upgrade) and HA/HR (handicap accessible or removable). The book notes HR cabinets may not meet ADA requirements.

For a wider look at standard sizes, our kitchen cabinet sizes guide lays out the common widths and heights.

Modifications and Accessories

Luxor, Concord and Classic each have a Modifications & Upgrades section with CT codes, and Luxor modifications require the cabinet to be assembled. The main ones:

• Depth reduction: CT-CUT-DEEP-B, -DB and -T cut base, drawer base and tall cabinets to 9, 12, 15, 18 or 21 inches; CT-CUT-DEEP-W cuts wall cabinets to 6, 9 or 11 inches.
• Extended wall depth: CT-EXD-W, to 15, 18, 21 or 24 inches.
• Chase cuts: CT-CHASE-B, -DB, -T and -W, with an accurate drawing supplied with the order.
• Glass: CT-DCG (door cut for glass), CT-DCG-GLI (cut and insert glass) and CT-DCG-GLI-F (frosted), plus PRT-GLS-SHELF glass shelf sets. Classic adds black aluminum frame glass doors (ACG codes) and custom glass doors with six glass types, from Low Iron Clear to Standard Reeded.
• Finished interior: CT-FINISH-B, -W and -T. Drawers are not finished.
• Toe kick: CT-TK-CUT, CT-TK-CUT-SHP, CT-TK-FLUSH and CT-TK-REDUCE (recessed).
• Other: CT-SHELF-FD full depth shelves, CT-TD-REDUCE for a shallower top drawer, CHARGE-SINK BASE to convert a B12, B15 or B18 to a sink base, and in Classic, width and height cuts plus a CT-BLUM hinge and glide upgrade.

The fillers, panels and moldings pages carry the trim: F330, F342 and F396 fillers, TKS toe kick with the TKS-CAP end cap, FS finished skins, REP refrigerator end panels, DWR dishwasher returns, crown molding (CRM, RCRM, MFLOCR) and LTRM light rail. Accessories include POS pull out shelves, F-SHELF floating shelves and five wood hood styles (WHM, WHB, WHC, WHS, WHT). Concord and Classic also list Rev-a-Shelf inserts and custom doors, panels and cabinets (DR-CUS, PL-CUS, CAB-CUS) quoted from your drawings.

How to Use the Spec Book When You Order

The book is most useful once you have a layout. Here is the order we recommend.

• Measure first. Get wall lengths, ceiling height and the window, door and appliance locations. Our measuring guide walks through it.
• Pick the collection, then build the list by code. Choose Bedford, Luxor, Concord or Classic from the construction pages, then write each cabinet as its exact code (B24, SB36, 3030) from that collection's section, since availability varies by door.
• Add the trim. Fillers, end panels, toe kick and molding are separate line items. Our guide to fillers, panels and toe kicks shows how much of each to plan for.
• Confirm the color. Paint and stain look different on screen, so we recommend you order door samples before placing the full order.
• Double-check modified items. CNC's policy pages say modified cabinets cannot be canceled or returned, so confirm depth cuts and glass doors before you approve.

You can shop the line on our CNC Cabinetry page, where prices are live. The spec book is not a price list, but we can price any code in it, including items not listed on our site. Send us the code and we will quote it. If you would like us to check the layout, send your measurements for a free 3D kitchen design and an itemized quote by code.

Still deciding on the brand? Our review of whether CNC Cabinetry is good covers the collections in more depth, and shoppers who want the widest finish selection and Designer options should also look at Fabuwood cabinets, our premium line.
