The Eurocraft spec book is the Signature Series Specification Catalog, Eurocraft Cabinetry's 102-page reference for its frameless, assembled-only cabinets made in Davie, Florida, and you can download the 2026 PDF below. It covers every door style and finish, the box construction, over 900 line items by code, modifications, panels, fillers and moldings. This guide shows where each part lives and how to use it when you order.
Download the Eurocraft Spec Book (PDF)
The complete 2026 book from Eurocraft Cabinetry: 102 pages, PDF, 16.8 MB, compressed for a faster download.
Download the PDF Shop EurocraftWhat Is in the Eurocraft Spec Book
The 2026 Signature Series catalog runs 102 pages: construction and doors up front, the cabinet catalog in the middle, then accessories, policies and samples. Page numbers below are the ones printed in the book.
| Section | Pages | What you will find there |
|---|---|---|
| Introduction and box construction | 4-5 | Company overview and a labeled cutaway of the cabinet box |
| Door construction | 6-11 | Core, edgeband, stile and rail widths and size limits for each door type |
| Door finishes | 12-23 | Every color swatch with its three-letter finish code |
| Price level charts | 24-29 | The price level assigned to each finish |
| Modifications | 30 | Depth changes, finished interiors, combined wall cabinets and touch-to-open options |
| Wall cabinets | 32-51 | Standard, refrigerator, blind, corner, microwave, lift-up, open and glass door wall units |
| Base cabinets | 52-61 | Door, drawer, sink, wastebasket, blind and corner bases |
| Vanity cabinets | 62-69 | Floor and hanging vanities, consoles and drawer units |
| Tall cabinets | 70-73 | Pantry and oven cabinets from 84" to 96" high, plus loose oven panels |
| Hardware and accessories | 74 | Replacement hinges, drawer glides, shelf clips and Axilo legs and tools |
| Panels, fillers, overlays, decorative doors | 75-79 | End and back panels, fillers and overlays |
| Shelves, roll outs, pull outs, drawer accessories | 80-83 | Loose shelves, roll outs and drawer inserts |
| Moldings and Axilo system | 84-85 | Toe kick, valance, crown and the Axilo leg system |
| Policies, payment and warranty | 86-89 | Ordering terms, production cycle and the Signature Series warranty |
| Glossary | 90-91 | How each material and finish behaves |
| Shipping, receiving and claims | 92-95 | Delivery options, inspection at delivery and the claim form |
| Samples and sales aids | 96-101 | Finish blocks, door samples and molding sample sets by code |
The cover says it plainly: available assembled only, manufactured and assembled in the USA. Eurocraft ships from Davie, Florida.
Door Styles and Finishes Covered
Every Signature door sits on the same frameless box. The book groups doors into slab materials (Venice, Alvic and Wilsonart), the 3DL Shaker doors and the Signature Premium collection. Each finish has a three-letter code that goes on your order.
| Door style | What it looks like | Finishes and codes |
|---|---|---|
| Venice Textured (slab) | Flat slab with a textured wood grain face, grain vertical by default | White Oak (VTW), Red Oak (VTR), Pecan (VTP), Yellow Oak (VTY), Dark Oak (VTD), Medium Oak (VTM), Barcelona Oak (VTB), Metallica (VMA) |
| Venice High Gloss (slab) | Flat slab in a high gloss solid color | Gloss White (VGW), Gloss Gray (VGG), Gloss Black (VGB), Gloss Platinum (VGP) |
| Venice Super Matte (slab) | Flat slab in a matte solid color | Matte White (VMW), Matte Gray (VMG), Matte Nautical (VMN), Matte Black (VMB), Matte Cashmere (VMC), Matte Olive Green (VMO), Matte Platinum (VMP) |
| Alvic Syncron (slab) | Textured surface on an 18 mm core | Como Ash 01 (CO1), Ice Cream 01 (IC1), Muratti 01 (MU1), Muratti 04 (MU4) |
| Alvic Zenit (slab) | Supermatte surface on 18 mm MDF | Basalto (BAM), Blanco (BLM), Antracita (ANM), Gris Nube (GRM), Cashmere (CAM) |
| Alvic Luxe (slab) | High gloss surface on 18 mm MDF | Blanco (BLG), Cashmere (CAG), Azul Indigo (AZG), Gris Nube (GRG), Antracita (ANG) |
| Wilsonart (slab) | Textured slab in Wilsonart laminate colors, each listed with its Wilsonart number | Designer White (WDW), Crisp Linen (WCL), White Cypress (WWC), Phantom Ecru (WPE), Wheat Tabby (WWT), Grigio Tessere (WGT), High Line (WHL), Phantom Charcoal (WPC), Fairchild (WFC), Friston Ash (WFA), Avondale Ash (WAA), Daintree (WDE), Dering Forest (WDF), Randolph Forest (WRF), White River Forest (WWR), Valley Forge Elm (WVF), Black Hills Oak (WBH), Helena Walnut (WHW), Neo Walnut (WNW) |
| 3DL Slim Shaker | Square, transitional door with a flat drop-in panel, membrane pressed, matte finish | Gauntlet Gray (SLG), Haze Gray (SLH), Midnight Blue (SLB), Mist Beige (SLM), Stratus White (SLW) |
| 3DL Wide Shaker | Stile and rail detail for a 5-piece look, membrane pressed, matte finish | Gauntlet Gray (SHG), Haze Gray (SHH), Midnight Blue (SHB), Mist Beige (SHM), Stratus White (SHW) |
| Cambridge, Lexington, Atlanta (Premium) | 5-piece doors with 2-1/4" stiles and rails, painted MDF or stained maple, each with its own interior and center panel profile | Designer White, Cream, Platinum, Nautical Blue, Dark Shadow, White Wash, Apricot, Wheat, Coffee, Slate (codes start with C, L or A, such as CDW, LCM, ASL) |
| Malibu (Premium) | Slim 7/8" stiles and rails; the painted version is one-piece MDF with a 1/8" deep interior molding | The same ten colors, codes starting with M (MDW, MNB, MCF) |
| Venice (Premium) | The Venice door in five Premium colors | Designer White (VDW), Cream (VCM), Platinum (VPM), Nautical (VNB), Dark Shadow (VDS) |
On wood grain slabs, vertical grain is the default and Eurocraft does not bookmatch, so grain will not line up from door to drawer front. Tall cabinets, tall panels and tall fillers are not available on orders with horizontal grain. Alvic finger-pull doors, Alvic Shaker doors and non-stock Alvic colors are listed as available by quotation.
The glossary on pages 90-91 notes that the melamine and lacquer doors carry an antibacterial coating designed to reduce bacteria on the surface.
Construction and Specifications
Page 5 shows the box, and each cabinet section opens with a standards page. The book specifies:
- Box: 3/4" plywood, offered with a white melamine interior or a natural birch wood veneer interior.
- Back: 1/4" plywood, dadoed and fully captured, with nailer strips and top and back support rails.
- Assembly: wood dowel and quick screw construction, with glue and dowel sides.
- Frameless fit: 1/16" reveals on every door and header, 1/8" between double doors.
- Doors: engineered wood or MDF at 18 mm (nominal 3/4") with 1 mm edgeband matching the face. The 3DL doors use a 3/4" engineered core with a white TFL back as standard.
- Drawer boxes: full extension soft-close, in double wall gray metal or solid wood dovetail.
- Hinges: fully concealed, soft-closing and adjustable six ways.
- Shelves: base shelves are 18" deep and adjustable with full edge banding. Wall shelves are full depth and adjustable. Loose shelves are 3/4" plywood with an edgebanded front.
- Depths: wall cabinets are 13" nominal, base cabinets 24", vanities 21" and tall pantries 24".
- Toe kick and legs: an integrated 4-1/2" toe kick with a 3" recess. Four Hafele Axilo legs come with every base, vanity and tall cabinet, and bases finish at 34-1/2" tall.
- Exposed ends: a 3/4" panel or decorative door finishes each exposed end. Top, bottom and back finishing is not available on wall cabinets.
- Warranty: five years from the date of purchase against defects in materials and workmanship, for the original purchaser in residential use. It covers repair or replacement of the defective part.
The ordering terms list a four to six week production cycle, starting the business day after the order is placed.
How to Read the Eurocraft Cabinet Codes
Eurocraft codes start with letters for the cabinet type, then the size in inches. Wall codes give width, then height. Base and vanity codes give width only, since height and depth are standard. Tall pantry and refrigerator codes add a third number for depth.
A few suffixes matter. A -1 on a 24" wide code means the single door version (B24-1, W2430-1). L and R on blind cabinets tell you which side the blind is on. FD means full height door, as in B30FD or SB36FD. An H after the V on vanity codes means hanging, as in VHB or VHSB, and most hanging vanity codes carry a 24 for their 24" height.
| Code | What it means |
|---|---|
| W3030 | Wall cabinet, 30" wide x 30" high, double door, 13" deep |
| W2430-1 | Wall cabinet, 24" wide x 30" high, single door version (W2430 is the double door) |
| WR362424 | Refrigerator wall cabinet, 36" wide x 24" high x 24" deep |
| WBC3630L | Wall blind corner cabinet, 36" wide x 30" high, blind on the left |
| B30 | Base cabinet, 30" wide, double door, 24" deep |
| B24-1 | Base cabinet, 24" wide, single door |
| SB36 | Sink base, 36" wide, double door |
| 3DB18 | Three drawer base, 18" wide |
| BLS3636 | Base lazy susan corner, 36" x 36" |
| BWB18 | Base wastebasket, 18" wide, two bins |
| VSB30 | Vanity sink base, 30" wide, 21" deep |
| VHSB3024 | Hanging vanity sink base, 30" wide x 24" high |
| TP189624 | Tall pantry, 18" wide x 96" high x 24" deep |
| TOD3390 | Tall double oven cabinet, 33" wide x 90" high |
Wall cabinets come 12" to 60" high and 9" to 48" wide, with 9" widths starting at 30" high. Base cabinets run 6" to 42" wide at 24" deep, with the 6" size offered as a full height door base (B6FD). Tall pantries and oven cabinets come 84", 87", 90", 93" and 96" high, including the 4-1/2" toe kick, so check your ceiling before ordering a 96" unit.
Modifications and Accessories
Page 30 lists the factory modifications, all subject to factory review:
- Depth changes: WRD and WID reduce or increase wall depth in 1" steps, from a 6" minimum to a 30" maximum. BRD, BID, TRD and TID change base and tall depth in 3" steps, from 15" to 30".
- Finished interiors: WFI, BFI and TFI finish the inside to match the door, with an 18 mm back and 18 mm shelves.
- Combined wall cabinets: WSC joins two wall cabinets in height, up to 96".
- Touch to open: WTL and TTL add a Salice touch latch per door, and BTL swaps soft-close drawer glides for Salice SMOVE touch-to-open glides.
End panels include BDD for bases, VDD for vanities, WDD30 for a 30" wall and TDD96 for tall. PFWE330 is a wall end panel with a 3" filler return. Fillers come 3" and 6" wide (WF330, TF396), and slab overlays such as OWF330 measure 2-7/8" x 29-7/8" to keep the reveal. Decorative overlay doors (ODB, ODW30) match the cabinet box they cover.
Inside the cabinet you can add roll out trays (ROT12 to ROT48, 4" high and 21" deep, on soft-close undermount slides), loose shelves (SHB, SHW, SHV) and drawer inserts such as the 4SDI-36-1 spice insert. Moldings include the MTK96 toe kick, MLV96 light valance and three crowns: cove CM8-C, shaker CM8-S and colonial CCM8-C. Crown needs an attachment rail, and the book recommends a TF396.
How to Use the Eurocraft Spec Book When You Order
Step 1: Measure the room. Our guide on how to measure a kitchen for cabinets covers wall lengths, ceiling height, windows and appliances.
Step 2: Build your list by code. Pick the door and finish code, then list each cabinet using the codes in the wall, base, vanity and tall sections. New to frameless? Our Eurocraft frameless cabinets guide explains it.
Step 3: Add fillers, panels and toe kick. Every exposed end needs a panel, blind cabinets are best pulled 3" from the wall with a filler, and toe kick board comes in MTK96 lengths. See our guide to fillers, panels and toe kicks.
Step 4: Confirm the color. Screens shift color, so we recommend you order door samples of your top picks before the full order.
Step 5: Send it to us. Send your list or measurements for a free 3D kitchen design and an itemized quote. We can price any code in this book, including items not shown on our Eurocraft cabinets page, so just send the code. Shoppers who want the widest finish range and Designer options should also compare our Fabuwood cabinets, our premium line.
Other Spec Books
- Fabuwood Allure Spec Book 2026
- Fabuwood Illume Spec Book 2026
- Fabuwood Ovela Spec Book 2026
- Fabuwood Quest Spec Book 2026
- Fabuwood Value Premium Spec Book 2026
- Jarlin Cabinetry Spec Book 2026
- KCD Spec Book 2026
- CNC Cabinetry Spec Book 2026
- All cabinet spec books in one place
Direct Cabinet Deals is an authorized online dealer for Fabuwood, Jarlin, Kitchen Cabinet Distributors (KCD), CNC Cabinetry and Eurocraft. We sell cabinets online and help you plan, price and order your kitchen. The spec book is published by Eurocraft Cabinetry, which keeps the current edition on its own site.
Ready to Shop Eurocraft?
Send us your cabinet list or your measurements. We can price any code in the Eurocraft spec book, order door samples to check your finish, or map out your kitchen in 3D at no charge.
Shop Eurocraft Free 3D DesignWhere can I download the Eurocraft spec book?
The 2026 Eurocraft Signature Series Specification Catalog is linked in the download box above as a PDF. It covers door styles, finishes, box construction, every cabinet code, modifications, panels, fillers and moldings across 102 pages.
What does W3030 mean in the Eurocraft spec book?
W3030 is a wall cabinet 30" wide and 30" high. The first two digits after W are the width and the last two are the height. Eurocraft wall cabinets are 13" deep, and a 24" wide wall cabinet with a -1 suffix is the single door version.
Does the Eurocraft spec book include prices?
The catalog assigns each finish a price level and prints Eurocraft's list prices by level. Prices for listed items are live on our Eurocraft cabinets page, and we can quote any other code if you send us your list.
Are Eurocraft Signature Series cabinets frameless and assembled?
Yes. The Signature Series is a frameless line with full overlay doors and 1/16" reveals, and it is available assembled only. The boxes are 3/4" plywood with a white melamine or natural birch veneer interior, manufactured and assembled in the USA.
What is the warranty on Eurocraft Signature Series cabinets?
The spec book lists a five year warranty from the date of purchase against defects in materials and workmanship. It applies to the original purchaser in residential use and covers repair or replacement of the defective part.
