Coffee Bar and Wet Bar Cabinets: Ideas, Sizes and Layouts

Coffee bar cabinets are one of the most rewarding upgrades you can add to a kitchen, dining room, or finished basement, and with factory-direct pricing from Fabuwood, building a dedicated bar run costs far less than most homeowners expect. Whether you want a sleek countertop coffee station or a full wet bar with an undercounter fridge and sink, this guide walks you through cabinet sizes, typical layouts, appliance openings, and everything else you need to order confidently.

Where a Bar Cabinet Run Actually Fits

A bar does not have to live in a basement. The three most popular locations are a kitchen wall opposite the main run, a butler's pantry between the kitchen and dining room, and a dedicated wall in a finished basement or family room. Each location shapes which cabinet types you need.

In the kitchen, a bar run typically borrows a section of wall cabinetry and base cabinetry that would otherwise hold dishes or pantry goods. In a dining room nook, the run is often shallower and taller, with open shelving above the countertop. In a basement, you have more flexibility for a longer run and a full wet bar with a sink.

Before you choose cabinet sizes, measure the wall carefully, note any windows or outlets, and confirm where your plumbing rough-in sits if you plan a wet bar sink. A complimentary layout session through our Free 3D Design service can map all of this before you place a single order.

Cabinet Sizes for a Bar Run

Bar cabinets pull from the same standard sizes used in kitchens. Understanding which sizes to combine gives you the most flexibility. For a deep reference on all standard dimensions, see our kitchen cabinet sizes guide.

Base cabinets are the backbone of any bar run. Standard depth is 24 inches, and widths run from 9 inches to 36 inches in 3-inch increments. A 30-inch or 33-inch base gives you room for a small sink. A 15-inch or 18-inch base works well as a filler next to an undercounter fridge opening.

Wall cabinets mount above the countertop and typically sit 12 inches deep. Heights of 30 inches, 36 inches, and 42 inches are all common. For a bar, 30-inch wall cabinets leave breathing room between the countertop and the bottom of the cabinet, which is especially useful if you want pendant lighting or open display space.

Tall cabinets (84 inches or 96 inches) work as pantry-style storage on either end of a bar run, holding glassware, bottles, or a built-in wine rack insert.

Openings for a Beverage Center or Undercounter Fridge

An undercounter beverage center or wine fridge slots into the base cabinet run the same way a dishwasher does in a kitchen. You frame the opening with standard base cabinets on each side, and the appliance slides in flush.

Most 24-inch-wide undercounter fridges need a finished opening that is exactly 24 inches wide and 34.5 inches tall (to match countertop height). Some compact 15-inch or 18-inch beverage centers also exist. Always pull the spec sheet for the exact appliance you plan to use and confirm the required rough opening before you order cabinets.

If you want a panel-ready appliance (one designed to accept a cabinet door panel so it blends in seamlessly), the panel dimensions come directly from the appliance manufacturer's spec sheet. Order those dimensions from the same cabinet line you use for the rest of the run so the finish and door style match exactly. Do not estimate the panel size; use the spec sheet numbers.

Leave a filler strip of at least 3 inches on the hinge side of any panel-ready unit so the door can swing open fully without hitting the adjacent cabinet.

Open Shelving and Glass Door Options

A bar run looks best when it mixes closed storage with display space. Open shelves between wall cabinets show off glassware and bottles without the cost of additional doors. Glass-door wall cabinets (with mullion frames or full-glass inserts) accomplish the same thing while keeping dust off your stemware.

Fabuwood offers glass door options across several lines, including the popular Fabuwood Allure family, in finishes that range from bright whites and soft grays to rich wood tones. Mixing one or two glass-door wall cabinets with solid doors gives the run a curated look without overwhelming the space.

For a frameless, flat-front aesthetic that suits a modern basement bar, Fabuwood Illume and Ovela are excellent fits. Both lines use full-overlay frameless construction and come in contemporary finishes. Jarlin cabinets, which ship in a solid plywood framed box with dovetail drawers, are a strong value alternative if you prefer a traditional shaker or raised-panel look for a lower budget.

Plumbing a Wet Bar Sink

A wet bar sink turns a beverage station into a fully functional bar. You need a supply line (hot and cold), a drain line, and ideally a trap that ties into an existing stack. In a basement, this often means running new drain lines through the slab or along the ceiling of a crawl space, which is a job for a licensed plumber.

For the cabinet side, choose a base sink cabinet in the width that fits your bar sink. A 24-inch or 30-inch base sink cabinet is typical for a small bar sink. These cabinets have no floor shelf so the plumbing has room to run. The sink cabinet sits in the run just like a standard kitchen sink base, and your countertop gets cut out to accept the sink bowl.

If you are not adding plumbing but want the option later, order a sink base now and cap the rough-in. Retrofitting a drain later is much easier when the cabinet opening is already sized correctly.

Sample Bar Cabinet Layouts by Run Length

The table below shows four common bar run lengths and one practical cabinet combination for each. These are starting points, not rigid prescriptions. Mix and match widths to hit your exact wall dimension, and use our Free 3D Design service to verify the layout before ordering.

Cabinet codes above follow standard naming conventions (B = base, W = wall, T = tall; numbers indicate width then height in inches). Verify exact SKUs in our cabinet shop or ask our design team to pull the correct part numbers for your chosen line.

If you also want to plan hidden storage for small appliances at the countertop level, our related article on appliance garage ideas covers that territory separately.

Choosing the Right Finish and Door Style for a Bar

A bar cabinet run is often visible from a living or dining space, so the finish matters more than it might in a pantry. Fabuwood's Allure line in a rich wood tone or a deep two-tone combination (white lowers, navy or forest green uppers) consistently photographs well and feels intentional rather than utilitarian.

For door style, a classic shaker door works in almost any home. A slab door reads as more contemporary and pairs well with the frameless construction of Fabuwood Illume or Ovela. Raised panel doors suit traditional or transitional dining rooms.

If you want to feel the finish before ordering, door samples are available and ship within 5 to 8 days. Order from the door samples page to compare finishes side by side in your actual lighting conditions.

Fabuwood and Jarlin orders typically arrive in 2 to 4 weeks, and many arrive sooner. Kitchen Cabinet Distributors (KCD) and Eurocraft orders also typically arrive in 2 to 4 weeks, and CNC Cabinetry stocked finishes in 2 to 4 weeks (CNC PLUS colors take 4 to 7 weeks).
